Amperage Is the Core of Welding Control

Every welding project hinges on one critical adjustment: amperage. Too little current, and the metal won’t fuse; too much, and you’ll burn through thin sheets or warp thick plates. Yet for most welders—beginners and seasoned pros alike—amperage remains a source of guesswork. They flip through charts, test random settings, and waste time reworking welds that could have been perfect with the right current.

Amperage isn’t just a number on a dial—it’s the amount of electrical current flowing through the arc, directly controlling heat input, penetration depth, and weld bead size. It dictates how the molten metal behaves: whether it spreads smoothly, penetrates deeply, or stays contained to avoid damage. Whether you’re welding 1mm sheet steel or 12mm plate, mild steel or stainless steel, the right Sefaspe welder amperage turns frustration into flawless results.

In this guide, we’ll demystify welding amperage. We’ll cover how to calculate the ideal current for your metal thickness and welding process, adjust amperage for different scenarios like vertical vs. flat welding, troubleshoot common amperage-related mistakes, and master advanced techniques to fine-tune settings. By the end, you’ll no longer rely on trial and error—you’ll use amperage as a precision tool to customize every weld with your Sefaspe MIG, TIG, or Stick welder.

Understanding Amperage: What It Does and Why It Matters

The Science of Current and Heat

Amperage (measured in amps, A) is the foundation of welding heat input. It works in tandem with voltage and travel speed to determine how much thermal energy is transferred to the base metal:

• Heat Input: Higher amperage = more heat = deeper penetration and wider weld beads.

• Penetration: Depth to which the weld fuses with the base metal—critical for joint strength.

• Bead Size: Higher amperage produces wider, flatter beads; lower amperage creates narrower, more convex beads.



Amperage vs. Voltage: What’s the Difference?

While amperage controls heat and penetration, voltage shapes the arc:

• Amperage: Think of it as the “power” of the arc—how much heat it generates.

• Voltage: Controls arc length and width—higher voltage = longer, wider arc; lower voltage = shorter, more focused arc.



For balanced results, amperage and voltage must be paired correctly. A general rule: For every 20A increase in amperage, adjust voltage by 0.5–1V. For example:

• 80A → 18–20V

• 120A → 20–22V

• 180A → 22–24V



Why Amperage Is Non-Negotiable

• Too Low Amperage: Causes incomplete fusion, cold lap, and narrow, weak beads—common when welding thick metal with insufficient heat.

• Too High Amperage: Leads to burn-through, warping, excessive spatter, and brittle welds.



How to Calculate the Right Amperage for Metal Thickness

Precision Over Guesswork

The most reliable way to set welding amps is to match them to your metal thickness and welding process. Use these guidelines as a starting point—adjust based on your specific project and your Sefaspe welder model.

Adjusting for Non-Mild Steel

Different metals conduct heat differently—adjust amperage accordingly:

• Stainless Steel: Reduce amperage by 10–15% to prevent warping and corrosion.

• Aluminum: Increase amperage by 20–30% for proper penetration.

• Cast Iron: Use lower amperage (10–15% less) to avoid cracking.


The “Test Weld” Method

Even with guidelines, always do a test weld on scrap metal:

1. Set amperage based on the chart above.


2. Weld a short bead (2–3 inches) on a scrap of the same thickness and metal type.


3. Inspect the bead:


• • If narrow, low penetration, or incomplete fusion, increase amperage by 10–20A.

  • If wide, burn-through, or warping—decrease amperage by 10–20A.


4. Repeat until smooth, even penetration is achieved.



Amperage Adjustments for Welding Process and Position

One Size Doesn’t Fit All

The right amperage changes based on your welding process (MIG, TIG, Stick) and position (flat, vertical, overhead).

Amperage by Welding Process

• MIG Welding: Most forgiving. Higher amperage for thick metal/flux-cored wire; lower for thin metal/solid wire.

• TIG Welding: Requires precise control. Lower for thin metal, higher for thick metal with larger tungsten.

• Stick Welding: Match amperage to electrode size:



Amperage by Welding Position

• Flat: Full amperage.

• Horizontal: Reduce 10–15%.

• Vertical: Reduce 15–20%.

• Overhead: Reduce 20–25%.



Troubleshooting Common Amperage-Related Mistakes

Burn-Through (Holes in Thin Metal)

• Cause: Too high amperage, slow travel speed, wide joint gap.

• Fixes: Reduce amperage by 10–20A, increase travel speed, close joint gap, and weld in short stitches.



Warping (Bent or Twisted Metal)

• Cause: Excessive heat or unbalanced welding.

• Fixes: Lower amperage 10–15%, use smaller beads, weld in sequence, clamp metal during cooling.



Incomplete Fusion

• Cause: Amperage too low, travel too fast, arc too long.

• Fixes: Increase amperage to 10–20A, slow travel, shorten arc length, and bevel thick metal.



Excessive Spatter

• Cause: High amperage, mismatched voltage, dirty metal.

• Fixes: Reduce amperage to 10A, adjust voltage, and clean metal before welding.



Advanced Amperage Techniques for Pro-Level Results

Pulse Amperage (MIG/TIG)

Pulse welding alternates high “peak” and low “background” amperage:

• Benefits: Reduces heat while maintaining penetration, ideal for thin metal, aluminum, vertical/overhead welding.

• Settings: Peak 20–30% higher, background 50% of peak, frequency 10–20 Hz.



Amperage for Root Pass vs. Fill/Cover Passes

• Root Pass: Lower amperage (10–15% less) for controlled penetration.

• Fill Passes: Medium amperage for even build-up.

• Cover Pass: Slightly higher amperage for a smooth finish.



Adjusting for Windy or Cold Environments

• Windy: Increase 10–15% for MIG/TIG.

• Cold: Increase 10–20%, especially for thick metal.



Amperage Mastery = Consistent, Professional Welds

Sefaspe welders make mastering amperage simple. Understanding how amps control heat and penetration, calculating the right current, and troubleshooting mistakes will eliminate guesswork and ensure flawless welds every time.

Practice and observation are key: lower amperage if burn-through occurs, raise it if fusion is incomplete. Over time, you’ll develop a feel for what works—no chart required.

Whether you’re a DIYer crafting garden projects or a professional fabricating structural components, amperage is your most powerful tool. With this guide and a Sefaspe MIG, TIG, or Stick welder, you can turn ordinary projects into extraordinary results.

Safety Note: Always wear PPE (helmet, gloves, flame-resistant clothing), ensure ventilation, and keep a fire extinguisher nearby. Consult a certified welder for structural projects.
